Power Integrations announced the LinkSwitch-XT2SR family of off-line, constant-voltage (CV), non-isolated flyback switcher ICs. The new devices feature exceptionally high efficiency of up to 90 percent for small open-frame power supplies.

With no-load consumption below 5 mW, LinkSwitch-XT2SR ICs easily surpass the requirements of the European Union’s Energy-Related Products (ErP) Directive for standby power consumption. The new ICs deliver 250 mW to the load within the 300 mW ErP allowance, enabling designers of appliances and industrial systems to operate more system functionality in standby mode, enhancing the user experience and saving energy.

Capable of delivering up to 15 W at 230 VAC, LinkSwitch-XT2SR multi-output flyback switcher ICs reduce the component count by incorporating a synchronous rectifier driver and an auxiliary, low-current, µV_cc output to directly supply an MCU. Advanced protection and safety features include hysteretic thermal shutdown (OTP) and extended creepage between the drain pin and all other pins, improving field reliability. The 725 V MOSFET provides excellent surge withstand performance, while a 900 V switch is available for industrial applications and for geographies where fluctuating mains voltages call for an extra safety margin.

LinkSwitch-XT2SR ICs prices start at $0.50 each in 1,000-unit quantities. Supporting materials include RDK-962, a reference design (hardware) kit for a 12 W power supply with 90 to 265 VAC input and dual 5 V / 1.4 A and 12 V / 0.42 A outputs; DER-963, a design example report which describes an 85 to 265 VAC input, 5 V / 1 A output, 5 W non-isolated flyback converter; DER-998, a design example report which details a 90 to 265 VAC input, 12 V / 1 A or 6 V / 1 A output power supply with 12 V or 6 V selectable output voltage; LinkSwitch-XT2SR data sheet; and a LinkSwitch-XT2SR video.
