Magnachip Semiconductor Corporation announced that the company has released a new Low-dropout (LDO) linear regulator featuring an ultra-fast transient response for a Universal Flash Storage (UFS)-based Multi-Chip Package (MCP).

UFS is an advanced version of an Embedded Multi-Media Controller (eMMC), which was developed for concurrent read and write performance at higher speeds. UFS-based MCP is a memory module that integrates UFS controller and memory ICs, such as DRAM or NAND flash. It is mainly used for the storage function in smartphones.

Magnachip’s LDO linear regulator is designed for the power supply of NAND flash in UFS-based MCP with an input voltage of up to 500mA. It reduces input noise with its power supply rejection ratio function while providing a low-leakage current of 75uA in deep sleep mode, which will enhance battery life and power efficiency.

A key feature of this new product is an ultra-fast transient response, minimizing output-voltage fluctuations. Frequent changes in voltage normally occur in UFS-based MCPs due to varying levels of reading and write performance. However, ultra-fast transient response regulates these fluctuations to a steady-state within 100 nanoseconds.

The line regulation and load regulation in UFS-based MCP are maintained at 0.2% and 0.5% respectively, which will guarantee a stable power supply. In addition, the dropout voltage is as low as 0.3V, which makes the linear regulator perfect for low-power domain operations of batteries.

This linear regulator also ensures robust circuit protection, such as overcurrent protection, thermal shutdown, and the power good signal, which indicates that all of the output voltages are within specification.
